Master Tinter

The Aoto Universal Refinish Mastertints is based on a unique, multi-function and universal system. Aoto universal concentrated tints can be used in combination with a series of different types of binders to deliver all solvent base quality paints for most type of paint job requirements.

With only one single mixing machine for all solvent base quality paints, there will be more productivity and output, with a lesser cost and investment. With our data banking of formulas, we can provide precise color matching solutions. It is an example of ultimate technology with simplicity. We continuously do research and development to constantly improve our products and come up with innovative products. Now you can have a greater range of finish options and colour capabilities from a smaller range of products.

The Aoto Universal Refinish Mastertints system is supported by an extensive distribution network that provides technical, colour and sales support on request.

All Aoto Universal Refinish Mastertints are cost effective and reasonably priced. We aim to produce more environment-friendly products. It is probably one of the most effective technologies available for today´s modern and progressive body shop.

Aoto Mixing Tinter
Code Name Description
A1 White High Strength Darker in flat angle, lighter in light angle and darker in near specular angle.
A2 White Low Strength Low strength of A1. Change A1 to A2 = Concentration A1 x 10.
A3A Micro White Used in aluminiums to make the near specular angle more yelloo and the high angle more blue and lighter. Use no more than 7% on formula weight to avoid durability problems.
A4 Super Black (solid black used as dominant color, ground coat has little)yellow , plug A27 will more blue.
A4A Super Jet Black Used in black solid colors. Strongest and most saturated black tint
A950 Solid Black Used in black solid colors. Strongest and most saturated black tint
A5 Jet Black Used in black solid colors. Strongest and most saturated black tint. Change A6 to A5 = Concentration of A6 x 2.
A6 Black High Strength Shading black.In metallic colors it has a yellow undertone.
A7 Black Low Strength Change A6 to A7 when the concentration of A6 is less than 0.45%; when concentration of A7 is greater than 8% use A6.
A101 White High Strength Darker in flat angle,lighter in light angle and darker in near specular angle.
A20 Violet Greener in side on angle. Very saturated red violet.
A21 Violet Blue More muddy and reddish violet than A20. More green effect under yellow light than A20.
A26 Orange Blue Green in near specular, red in head on angle and more red in side-on angle. Transparent tint.
A27 Transparent Blue Green blue in the side on angle, red in near specular angle.
A28 Fast Blue High Transparent Red blue in flat angle. Transparent pigment
A29 Light Blue Green in head on angle. Greener under incandescent.
A30 Fast Green High Transparent Bluish green tint.
A31 Fast Green Low Transparent Bluish green.
A32 Green Yellow green tint.
A33 Green Gold Transparent yellow green tint, used in metallic colors and green effect under white light.
A38 Flattening Agent Make the Aluminium floating, the basecoat darker, the ground coat lighter and more shining.
A41 Yellow Transparent yellow tint, used in solid colour, has good hiding.
A42 Light Yellow Saturated yellow tint, most greenish lead chromate. Only used in an emergency or as a last resort in metallic colors.
A43 Bright Yellow Transparent yellow tint, more reddish yellow tint under yellow light. Becomes light under sodium light.
A44 Medium Yellow Used in solid colors, has good hiding
A45 Transparent Yellow Do not use in single stage, subject to fade in light colors.
A46 Orange Yellow Green on head on, very green and light side on angle. Produces red near spec.
A48 Bright Orange Transparent orange tint, used in solid colour, has good hiding.
A50 Brilliant Red Dark under sodium light.
A51 Red Orange More reddish than A53.
A53 Red Orange The plain color is longer to use, lie between the A51, don't be use in a shallow color.
A55 Light Red Transparent red tint, saturated yellow tone red all angles.
A58 Deep Maroon Equal to A55 but redder and bluer.
A62 Transparent Red High Strength Clean blued tone red, less reddish red tint under the incandescent light.
A64 Magenta Blue tone red, the most reddish red tint for side on angle. Less saturated than A66.
A66 Red Violet The most desaturated blue toned red Most reddish under incandescent light.
A70 Fast Blue Low Change A28 to A70 when concentration of A28 is less than 0.45% of the total formula weight, when A70 is greater than 8% use A28. Reddest of all blues in incandescent light.
A80 Ochre Opaque tints, yellow tone. solid colour used - light and yellow at side on angle.
A81 Yellow Ochre High Strength For metallic the same effect as the white tint A1.
A82 Yellow Ochre Low Strength Opaque tints, green yellow tone. In metallic, effect equivalent to white tint A1 - light and yellow at side on angle, dark at near specular angle.
A84 Red Ochre Low Strength For metallic the same effect as the white tint A1. Light and yellow high angle.
A85A Transparent Maroon Replace A58, but more transparent. Equal to A55 but redder and bluer.
A88 Green Blue Green blue translucent tint, Green in the side on angle, little blue in near specular angle.
A90 Transoxide Yellow Most yellowish tint of the transoxide tints. Transparent tint, green and light high angle.
A91 Transoxide Red Transparent tint, red brown head on and side on angle.
A92 Transoxide Red Transparent tint, red head on and side on angle.
A93 Transoxide Brown Most reddish tint of the transoxide tints, less reddish tint of the transoxides under yellow light. Transparent tint.
A175 Matting Agent Blur effect
A22 Samco Blue
A35 Green Yellow
Aoto Mixing Tinter Alluminium
Code Name Description
A9 Super Fine Bright Aluminum Super Fine Aluminium, Dark flop, brighter and light near specular.
A10 Fine Aluminum Light at the side on angle, dark and muddy at the near specular angle.
A11 Medium Fine Aluminum The side-on angle becomes lighter.
A12 Medium Aluminum Flake size similar to A11, darker in near specular and head on than A11.
A13 Medium Coarse Aluminum Bright sparkle. Equivalent lightness effect on near specular angle, head on angle and side on angle.
A14 Coarse Aluminum Equivalent lightness effect on near specular, head on and side on angles.
A16 Medium Fine Aluminum Light at the side on angle, dark and muddy at the near specular angle.
A17 Fine Bright Aluminum Dark flop, brighter and light near specular.
AM17 Fine Bright Aluminum Dark flop, brighter and light near specular.
A94 Extra Coarse Aluminum Change A6 to A7 when the concentration of A6 is less than 0.45%; when concentration of A7 is greater than 8% use A6.
A95 Bright Coarse Aluminum Similar to A17 but coarser and brighter.
A97 Fine Extra Bright Aluminum Dark flop, brighter and light near specular
A117 Fine Bright Aluminum Fine Aluminium, Dark flop, brighter and light near specular
A133 Medium Coarse Aluminum Flake size similar to A11, darker in near specular and head on than A11.
A155 Fine Bright Aluminum Dark flop, brighter and light near specular.
A359 S.Bright Coares Aluminum Sparkling,brighter and light near specular.
A801 Bright Coarse Aluminum Sparkling,brighter and light near specular. Newest Silver tints using in Honda 2008-2009 colors.
A811 Hyper Silver Sparkling,brighter and light near specular
MS38 Chrome Silver Is the new hot color on the Corvette Wheel Market Chrome silver.can mixing colour
S38 Chrome Silver Is the new hot color on the Corvette Wheel Market Chrome silver.
S98 Chrome Silver Is the new hot color on the Corvette Wheel Market Chrome silver.
A8 Super Fine Aluminium
MS39 Super Silver
AM960 Special Fine Bright Aluminium
Aoto Mixing Tinter Pearl
Code Name Description
A71 Bronze Pearl Take a green copper color.
A72 Russet Pearl Opaque and medium particle size. Red colour effect under all viewing angle.
A73 White Pearl More bluish than aluminium near specular angle.
A74 Blue Pearl Blue under spotlight near specular angle.
A75 Super Green Pearl Very red on high angle.
A76 Yellow Pearl Provides yellow gold interference effect with light blue silk flop. Translucent and medium particle size.
A77 Copper Pearl Opaque, medium particle size, gives a copper tone effect at all angles.
A78 Gold Pearl Provides gold interference effect.
A79 Lilac Pearl Purple near specular angle bluish-yellow tone for side-on angle.
A721 Red Satin Pearl Opaque, fine-medium particle size.
A722 Mars Pearl
A724 Rutile Red Pearl Translucent, medium particle size, provides a red interference effect with a greenish-light at side on.
A727 Orange Pearl Provides orange interference effect.
A728 Red Green Pearl The medium white pearl, face to face more white.
A731 Fine Satin Pearl Translucent, fine particle size, provides a white misty shadow effect.
A741 Satin Blue Pearl Blue under spotlight near specular angle, fine-medium particle size.
A756 Blue Green Pearl Translucent, medium particle size, not an inteference type of pearl. Provides a strong clear blue brilliant color at the near specular angle.
A767 Yellow Pearl Provides yellow gold interference effect.
M72 L.Cost Russet Pearl More bluish than aluminium near specular angle.
M73 L.Cost White Pearl More bluish than aluminium near specular angle.
M74 L.Cost Blue Pearl Blue under spotlight near specular angle.
M75 L.Cost Super Green Pearl Very red on high angle.
M76 L.Cost Yellow Pearl Provides yellow gold interference effect with light blue silk flop. Translucent and medium particle size.
M79 L.Cost Lilac Pearl Purple near specular angle bluish-yellow tone for side-on angle.
M767 L.Cost Yellow Pearl Provides yellow gold interference effect.
M77 Copper Pearl
M78 Gold Pearl
M727 Orange Pearl
Aoto Mixing Tinter Crystal & X Crystal
Code Name Description
A725 Crystal Red Opaque and medium particle size. Red colour effect under all viewing angle.
A735 Crystal White More bluish than aluminium near specular angle.
A745 Crystal Blue Blue under spotlight near specular angle.
A755 Crystal Green Red on high angle.
A765 Crystal Gold Provides yellow gold interference effect with light blue silk flop. Translucent and medium particle size.
A775 Crystal Orange Opaque, medium particle size, gives a copper tone effect at all angles.
A795 Crystal Lilac Purple near specular angle bluish-yellow tone for side-on angle.
M735 L.Cost Crystal Pearl More bluish than aluminium near specular angle.
A973 X Crystal White Bright sparkle. Translucent pearl. = AM 725
A974 X Crystal Blue Bright sparkle. Translucent pearl. = AM 725
A975 X Crystal Lilac Bright sparkle. Translucent pearl. = AM 725
A976 X Crystal Yellow Bright sparkle. Translucent pearl. = AM 725
A979 Aluminium Orange
M745 Crystal Blue
M755 Crystal Green
M765 Crystal Gold
M775 Crystal Orange
AM795 Crystal Lilac
A924 Rutile Red Pearl
A999 X Crystal Lilac
Aoto Mixing Tinter Brilliant Effect
Code Name Description
A303 Brilliant Orange Transparent brilliant colour. limited lightfastness.
A304 Brilliant Yellow Transparent brilliant colour. limited lightfastness.
A304G Brilliant Yellow Transparent brilliant colour. limited lightfastness.
A305 Brilliant Green Transparent brilliant colour. limited lightfastness.
A307 Brilliant Blue Transparent brilliant colour. limited lightfastness.
A307G Brilliant Blue Transparent brilliant colour. limited lightfastness.
A308 Brilliant Red Transparent brilliant colour. limited lightfastness.
A309 Brilliant Magenta Transparent brilliant colour. limited lightfastness.
A310 Brilliant Black Transparent brilliant colour. limited lightfastness.
A312 Brilliant Purple Transparent brilliant colour. limited lightfastness.
M308 L.Cost Brilliant Red Transparent brilliant colour. limited lightfastness.
M855 L.Cost Brilliant Red
A318 Brilliand Red
Aoto Mixing Tinter Fluorescence Effect
Code Name Description
AF222 Fluorescence Pink Can mix the colour with AOTO Master Tinter and A140 Binder. limited lightfastness.
AF225 Fluorescence Green Can mix the colour with AOTO Master Tinter and A140 Binder. limited lightfastness.
AF226 Fluorescence Yellow Can mix the colour with AOTO Master Tinter and A140 Binder. limited lightfastness.
AF227 Fluorescence Orange Can mix the colour with AOTO Master Tinter and A140 Binder. limited lightfastness.
Binders
Code Name Description
A100 Polyurethane Binder Polyurethane Binder
A113 Wrinkle Binder Wrinkle Binder
A114 High Temperature Binder High Temperature Binder
A116 Crackle Binder Crackle Binder
A119 Texture Binder Texture Binder
A119B High Temperature Texture Binder High Temperature Texture Binder
A130 LMBase Coat Binder LMBase Coat Binder
A140 Solid Base Coat Binder Solid Base Coat Binder
A145 Solid Binder Solid Binder
A150 HM Base Coat Binder HM Base Coat Binder
A160 HM Base Coat Binder HM Base Coat Binder
A170 Polyurethane Binder Polyurethane Binder
A170B Polyurethane Aluminium Binder Polyurethane Aluminium Binder
A180 Leather Binder Leather Binder
A190 Glass Binder Glass Binder
A190G Glass Crackle Binder Glass Crackle Binder
A306 Leather Binder Leather Binder
A5000 Base Coat Slow Binder Base Coat Slow Binder
A111 Texture Binder Texture Binder
A118 Texture Binder Texture Binder
RPB Komodo Binder Komodo Binder
AZ111 Super Shine Binder Super Shine Binder
Aoto Special Effect
Code Name Description
A188 Rainbow Effect Fine particle size. Rainbow Effect at the side on angle.
A288 Rainbow Effect Fine particle size. Rainbow Effect at the side on angle. Concentration of A188 x 2.
A388 Rainbow Effect Fine particle size. Rainbow Effect at the side on angle. Concentration of A188 x 3.
A402 Diamond Red Bright sparkle, medium particle size.
A403 Diamond White Bright sparkle, medium particle size.
A404 Diamond Blue Bright sparkle, medium particle size.
A405 Diamond Green Bright sparkle, medium particle size.
A406 Diamond Gold Bright sparkle, medium particle size.
A409 Diamond Violet Bright sparkle, medium particle size.
A902 Lucky Star Medium particle size. Red at the side on angle, gold and green at the near specular angle
A904 Lucky Star Medium particle size. Blue at the side on angle, purple and red at the near specular angle
A905 Lucky Star Medium particle size. Green at the side on angle, gold and blue at the near specular angle
A909 Lucky Star Medium particle size. Purple at the side on angle, blue and red at the near specular angle
A910 Lucky Star Medium particle size. Red at the side on angle, gold and green at the near specular angle
A911 Super Diamond Bright sparkle, coarse particle size. Multi colour at the side on angle, blue at the near specular angle.
A921 Super Diamond XL Coarse particle size, Bright sparkle, Multi colour at the side on angle, gold at the near specular angle.
A922 Super Diamond Bright sparkle, coarse particle size. Multi colour at the side on angle, blue at the near specular angle.
A933 Super Diamond Bright sparkle, coarse particle size. Multi colour at the side on angle, blue at the near specular angle.
A955 Super Diamond Bright sparkle, coarse particle size. Multi colour at the side on angle, blue at the near specular angle.
A966 Super Diamond Bright sparkle, coarse particle size. Multi colour at the side on angle, blue at the near specular angle.
A988 Super Diamond Bright sparkle, coarse particle size. Multi colour at the side on angle, blue at the near specular angle.
A7240 Brilliant Illusion 3 tone colour at the different side on angle, red, orange and gold.
A7280 Brilliant Illusion 3 tone colour at the different side on angle, green, blue and purple.
A7500 Brilliant Illusion 3 tone colour at the different side on angle.
A7590 Brilliant Illusion 3 tone colour at the different side on angle, red, green
A8400 Brilliant Illusion 3 tone colour at the different side on angle.
A8500 Brilliant Illusion 3 tone colour at the different side on angle, blue grey, blue green and purple
A8900 Brilliant Illusion ChromaLusion multi-effect ,5 tone colour at the different side on angle, red, gold, green, blue and purple.
A9300 Brilliant Illusion ChromaLusion multi-effect ,5 tone colour at the different side on angle.
A9400 Brilliant Illusion ChromaLusion multi-effect ,5 tone colour at the different side on angle, blue, green, Glod, Red and purple.
A9500 Brilliant Illusion ChromaLusion multi-effect ,5 tone colour at the different side on angle, green, blue, purple, glod and red.
A9600 Brilliant Illusion ChromaLusion multi-effect ,5 tone colour at the different side on angle, gold, optic gold, green, light purple and light sea blue.
A9900 Brilliant Illusion ChromaLusion multi-effect ,5 tone colour at the different side on angle, blue, purple, red, orange and gold.
A7565 Crystal Blue Lilac
A7785 Leonis Gold
A7365 Brilliant Illusion
A7490 Brilliant Illusion
A7549 Brilliant Illusion
A7674 Brilliant Illusion
A7880 Brilliant Illusion
A7976 Brilliant Illusion
A8300 Brilliant Illusion
A9000 Brilliant Illusion
A9100 Brilliant Illusion
A9200 Brilliant Illusion
A9700 Brilliant Illusion
A9800 Brilliant Illusion
ASC84 Chemeleon Illusion
ASC85 Chemeleon Illusion
ASC87 Chemeleon Illusion
ASC88 Chemeleon Illusion
ASC89 Chemeleon Illusion
ASC99 Chemeleon Illusion
